| ►Interface: | RJ-45 jack for 10Base-T , ST Fiber connector | ►Technique: | Baseband |
| Category 3, 4 or 5 & 6up UTP cable for 10Base-T | ►LEDs: | Power, Lmon, Col, Jab, Xmt, RCV,LINK | |
| ►Cable type: | 9/125um Single-mode fiber cable for (MF-629S) | ►Cable length: | 100 meters max. for UTP |
| 62.5/125um Multi-mode fiber cable for (MF-629) | 20K meters max. for Single-mode (MF-629S) | ||
| ►External Power: | Input 110V or 220V AC Output 12V DC, 1 Amp | 2K meters max. for Multi-mode (MF-629) | |
| ►Temperature: | 0 to 55C (standard operating) | ►Dimensions: | 0.8" (H) x 2.2" (W) x 4.2" (D) |
| ►Humidity: | 10 to 90% (non-condensing) | ||
| ►Standard: | IEEE 802.3 10Base-T/10Base-2 | ||
| ►EMI: | Meets FCC Class A Subpart B of Part 15 Requirement |
