| ►Interface: | 1xRJ-45 Jack from (Hub/station) select switch | ►Technique: | Baseband |
| 1xBNC socket to 10 Base-2 | ►Lan Expansion: | Twisted Pair expand upon to 4 level | |
| ►Cable length: | 100 M max. per UTP cables | Thinnet up to 30 Hubs | |
| 185 M max. per Thin Ethernet | ►Dimensions: | 0.79" (H) x 2.17" (W) x 4.09" (D) | |
| ►External Power: | Input 110V or 220V AC Output 12V DC, 1 Amp | ►Topology: | Star |
| ►Temperature: | 0 to 55C (standard operating) | ►Protocol: | CSMA/CD |
| ►Humidity: | 10 to 90% (non-condensing) | ||
| ►Standard: | IEEE 802.3 10Base-T/10Base-2 | ||
| ►EMI: | Meets FCC Class A Subpart B of Part 15 Requirement |
