| ►Interface: | DB-15 male for thick Ethernet | ►Dimensions: | 0.74" (H) x 1.7" (W) x 3.7" (D) |
| ST connector for 10Base-FL | ►Switch: | SQE On/Off | |
| ►Cable length: | 50 M max .per Transceiver cable | ►Cable type: | |
| 2 km max.Fiber Optic Multi Mode cable(MF-628) | 62.5/125um Multi-mode duplex fiber optic cable | ||
| 20km max.Fiber Optic Single Mode cable(MF-628S) | 9/125um Single-mode duplex fiber optic cable | ||
| ►External Power: | Input 110V or 220V AC Output 12V DC, 1 Amp | ||
| ►Temperature: | 0 to 55C (standard operating) | ||
| ►Humidity: | 10 to 90% (non-condensing) | ||
| ►Standard: | IEEE 802.3 10Base-T/10Base-2 | ||
| ►EMI: | Meets FCC Class A Subpart B of Part 15 Requirement | ||
